CONNECTORS AND SEALING SOLUTIONS
Freudenberg Flow Technologies T-Seals are mostly used in stab and static applications for high cyclic pressure and temperature peaks of up to 15,000 psi and 210° C (410° F) or higher depending on housing design and material choice.
Traditional sealing solutions cannot provide adequate safety here. The separate PEEK anti-extrusion rings ensure high pressure resilience and excellent resistance to rolling and bunching. A standard range designed to suit AS568B O-ring housings is available to be retrofitted into original O-ring grooves in three standard lengths.
Used for many oil and gas applications in wellhead equipment, downhole and surface applications, Freudenberg Flow Technologies’ T seals are supplied in a wide range of materials. Custom sizes are also available.
Spring seals from Freudenberg Flow Technologies are available in commercial grades like NBR, HNBR, FKM and our high performance Gazguard® grades, engineered to offer superior performance in demanding applications, Norsok M-710 RGD, Norsok M-710 sour gas and ISO 10423 (API 6A) chemical ageing immersion and fixture testing and ISO 10423 F.1.11 pressure and thermal cycling testing.
